Magneto Generator Stator Fit for Kawasaki KFX 90 KSF 90 2007-2024 / Kymco Mongoose 90 2007-2018
Features:
Direct replacement to your original unit
Plug-and-play, direct fit, easy installation.
Highest grade lamination materials.
Pick up pulsar coil included.
Connector included.
Rubber grommet included.
All products shipped are tested.
Specifications:
Condition: Aftermarket 100% Brand New
Quanity: 1PC
Type: Stator Coil
Dimensions :
Interior diameter : 29mm / 1.14 inches
Exterior diameter : 87mm / 3.44" inches
Thickness : 22mm / 0.86 inches
Other Specifications :
Number of wires: 3
Number of pins: 3
Number of plugs: 1
Number of fixation holes: 2
Replacement Part Number:
31120-LBD4-900
31120-LBD4-90B
31120-LBD4-90A
21003-Y002
21003-Y005
21003-Y006
Fits Make/Model/Year:
Fit for Kymco KXR 90 Euro 2 2004-2006
Fit for Kymco Maxxer 90 2010-2016
Fit for Kymco Maxxer 90S 2017-2020
Fit for Kymco Mongoose 90 2007-2018
Fit for Kawasaki KFX90 KSF90 2007-2024
(Compatibility Chart is for Reference ONLY!!!)
(Please Compare with Your faulty unit and the image we provided to Decide Fitments)
Package Included:
1x Stator Generator
NOTICE:
Before installing your new stator
Check the AC output of the stator.
Replace any burned or corroded connectors on stator and regulator/rectifier.
Check and repair any melted wiring.
Use hi-temp dielectric grease on all connectors
Our stator may use a different wire color code than your original.
All of the wires are installed in the correct order; please do not change any of the wiring configurations.
This stator is designed as a direct plug-in replacement and should be used as such.
When bolting stator in, always use locking compound.
If our stator includes a pickup coil, always make sure the air gap is correct upon installation.
All item pictures are accurate; if in doubt do not hesitate to compare our item to your original part.
Battery condition is important. No stator can make up for a bad or weak battery. If in doubt charge your battery and have it load tested, or simply replace it.
ALWAYS START WITH A FULLY CHARGED BATTERY !
The product on offer is an accessory or spare part and thus is not an original product of the vehicle manufacturer.
The name of the vehicle manufacturer is stated only as an indication of the determination of the product being offered as an accessory or spare part, to clarify, for which vehicle the product on offer fits.
