1*M-6GHz RF amplifier 2*dB high gain driver receiving amplifier
Description:
This amplifier module is used for signal gain promotion and small signal amplification in various radio transmitters and receivers. The module covers the 1*M-6GHz*M-6GHz broadband frequency range, covers 433M, 1.2G, 1.5G, 2.4G, 5.8G and other typical application frequencies, and has a high flatness gain characteristic of 2*dB. It is used in transmitter signal gain promotion and receiver systems. The module uses a Type-c interface +5V power supply and has a power working indicator light.
Application scenario:
1. Beidou/GPS receiver
2. Receiver system (FM radio reception, radar reception, etc.)
3. Electromagnetic compatibility receiving system
4. Software Radio Receive
5. Intermediate frequency signal amplification
Specification:
Working voltage: +5V single power supply;
Power interface: Type-c interface;
Working current: 2*dB-75mA;
Working frequency: 1*M-6GHz;
Gain: 2*DB (refer to the measured curve for different frequencies);
P1dB output power: +12dBm@2GHz;
Noise coefficient: 4.5dB;
Input and output interface: SMA (external screw inner hole);
Module size: 46*3**12mm (excluding connector);
Module weight: 35g;
Weight: 6*g (including host+TYPE-C cable);
Current:<1**mA;
input-output impedance: 5* ohms
Package Included:
1 x 2*dB Amplifier Module
1 x TYPE-C Cable
