58mm Cylinder Piston Gasket Rebuild Kit For Yamaha FZ 16 Fazer 2010 2011 2012 2013 2014 2015
Features:
If your cylinder blows through, the compression is too low, or even a piston seizure has occurred, then this kit is exactly the right thing for you.
Kit includes cylinder, piston, rings, pin, clips & top end gasket kit (you get exactly what is pictured).
Piston is anodized for superior heat resistance and longer lifespan.
The gaskets use performance materials to increase durability and provide greater reliability.
Includes all gaskets pictured to rebuild top end.
Kit is for standard bore size - 58mm x 57,9mm stroke, 15mm steel piston pin.
Compression Ratio: 9.5:1.
This kit is excellent as a low-cost replacement for defects in the original cylinder.
Specifications:
Condition: Aftermarket 100% Brand New
Quantity: 1 Set
Material: Aluminum
Displacement: 153cc
Bore Type: Standard Bore
Cylinder Type: 21C00
Bore diameter: STD 58mm
Stroke: 57.9mm
Pin Diameter: 15mm
Replacement Part Number:
Cylinder: 21C-E1310-00
Cylinder Base Gasket: 21C-E1351-00
Cylinder Head Gasket: 21C-E1181-00
Piston (Std): 21C-E1631-00
Pin, Piston: 21C-E1633-00
Piston Ring Set (Std): 21C-E1603-00
Circlips, piston: 93450-16812
Valve Seal: 21C-E2119-00
Fits Models:
Fit for Yamaha FZ16 Fazer year: 2010 2011 2012 2013 2014 2015
Fit for Yamaha FZ 2.0 year: 2016 2017 2018
(Compatibility Chart is for Reference ONLY!!!)
(Please Compare with Your faulty unit and the image we provided to Decide Fitment)
Package Includes:
1x Cylinder
1x Piston
1x Piston Ring Set
1x 15mm Wristpin
1x Circlip(2)
1x Cylinder Base Gasket
1x Cylinder Head Gasket
2x Valve Stem Seals
Note:
Carefully compare to your old parts to be sure this is the correct part for your machine.
The product on offer is an accessory or spare part and thus is not an original product of the vehicle manufacturer.
The name of the vehicle manufacturer is stated only as an indication of the determination of the product being offered as an accessory or spare part, to clarify, for which vehicle the product on offer Fits.
Features:
If your cylinder blows through, the compression is too low, or even a piston seizure has occurred, then this kit is exactly the right thing for you.
Kit includes cylinder, piston, rings, pin, clips & top end gasket kit (you get exactly what is pictured).
Piston is anodized for superior heat resistance and longer lifespan.
The gaskets use performance materials to increase durability and provide greater reliability.
Includes all gaskets pictured to rebuild top end.
Kit is for standard bore size - 58mm x 57,9mm stroke, 15mm steel piston pin.
Compression Ratio: 9.5:1.
This kit is excellent as a low-cost replacement for defects in the original cylinder.
Specifications:
Condition: Aftermarket 100% Brand New
Quantity: 1 Set
Material: Aluminum
Displacement: 153cc
Bore Type: Standard Bore
Cylinder Type: 21C00
Bore diameter: STD 58mm
Stroke: 57.9mm
Pin Diameter: 15mm
Replacement Part Number:
Cylinder: 21C-E1310-00
Cylinder Base Gasket: 21C-E1351-00
Cylinder Head Gasket: 21C-E1181-00
Piston (Std): 21C-E1631-00
Pin, Piston: 21C-E1633-00
Piston Ring Set (Std): 21C-E1603-00
Circlips, piston: 93450-16812
Valve Seal: 21C-E2119-00
Fits Models:
Fit for Yamaha FZ16 Fazer year: 2010 2011 2012 2013 2014 2015
Fit for Yamaha FZ 2.0 year: 2016 2017 2018
(Compatibility Chart is for Reference ONLY!!!)
(Please Compare with Your faulty unit and the image we provided to Decide Fitment)
Package Includes:
1x Cylinder
1x Piston
1x Piston Ring Set
1x 15mm Wristpin
1x Circlip(2)
1x Cylinder Base Gasket
1x Cylinder Head Gasket
2x Valve Stem Seals
Note:
Carefully compare to your old parts to be sure this is the correct part for your machine.
The product on offer is an accessory or spare part and thus is not an original product of the vehicle manufacturer.
The name of the vehicle manufacturer is stated only as an indication of the determination of the product being offered as an accessory or spare part, to clarify, for which vehicle the product on offer Fits.
