Air-Operated Double Diaphragm Pump 1-1/2" Inlet Outlet Petroleum Fluids Tool
Description :
Pneumatic diaphragm pumps can not only escort flowing liquids, but also transport some difficult-to-flow media.
It has many advantages of self-priming pumps, submersible pumps, canned pumps, mud pumps and impurity pumps.
Feature:
1: No need for irrigation and diversion, the suction lift is up to 7 meters, the lift is up to 50 meters, and the outlet pressure is ≥6 kgf/cm².
2: The flow is spacious and the passing performance is good. The maximum particle diameter allowed to pass is 4.5 mm. When pumping mud and impurities, there is little wear on the pump.
3: The head and flow can be adjusted steplessly through the opening of the air valve (air pressure adjustment between 1-7kgf/cm²).
4: The pump has no rotating parts, no shaft seal, and the pumped medium such as the diaphragm is completely separated from the moving parts of the pump and the workpiece medium,
and the transported medium will not leak outside. Therefore, when pumping toxic, volatile or corrosive media, it will not cause environmental pollution and endanger personal safety
5: There is no need to use electricity, and it is safe and reliable to use in flammable and explosive places.
6: After the exhaust port is connected to the liquid surface of the medium, it can be immersed in the medium to work.
7: It is easy to use and reliable in operation. It only needs to simply open and close the gas valve to start and stop. Even if the pump runs without medium for a long time or stops suddenly due to accidents, the pump
will not be damaged. Once overloaded, the pump will stop automatically. ,with self-protection performance, when the load returns to normal, it can start running automatically.
8: The structure is simple and there are few wearing parts. The pump has a simple structure and is easy to install and maintain. The medium conveyed by the pump will not touch the moving parts such
as the gas distribution valve and the connecting rod. Unlike other types of pumps, the rotor, piston, gear, etc. , blades and other components are worn and the performance gradually declines.
9: The pump does not need to be lubricated with oil, even if it is idling, it has no effect on the pump, which is a major feature of the pump.
Specifics:
Condition: 100% Brand New
Type: Air-operated double diaphragm
Body Material: Aluminum alloy
Inlet Port: 1-1/2 inch (40 mm)
Outlet Port: 1-1/2 inch (40 mm)
Air Inlet Size: NPT 2/5 inch (10 mm)
Average Air Consumption: 9 CFM
Max Flow rate: 8 m3/h (35.2 GPM)
Suction: 0-7 m (0-23 ft)
Max Suspended Solids: 4.5 mm (0.18 inch)
Max Head: 50 m (164.04 ft)
Max. PSI: 115
Operating PSI: 29-115
Max Fluid Temp.: 80 ℉
Package Size: 55 x 40 x 26 cm (21.65 x 15.75 x 10.24 inch)
Gross Weight: 15.6kg (34.4lbs)
Note:
1.Can not use for corrosive liquid.
2.Please allow 1-3mm difference due to manual measurement.
3.Please read this manual carefully before operating the pump!
4.Due to the light and screen difference, the item's color may be slightly different from the pictures.
Package Included:
1 x Air-Operated Double Diaphragm Pump
1 x Product Manual
