Engine Brake Adjustment Tool 7mm 3163530 Brake Feeler Gauge For Cummins ISX
Instructions:
1.Loosen the locknut on the brake lever adjusting screw, and back out the adjusting screw one turn
2.Insert the feeler gauge( 7mm-3163530), between the bottom of the engine brake piston and the top of the exhaust valve pin on the exhaust valve crosshead
3.Tighten the adjusting screw until drag on the feeler gauge is felt(Proper drag means that there is no motion of the brake lever camshaft follower against the cam lobe)
4.Hold the engine brake lever adjusting screw and tighten the locknut
Specifics:
Condition: 100% Brand New
Color: Black
Size: shown as pictures
Type: Engine Brake Adjustment Tool(7MM)
Material: Steel
Note£º
1.Do not insert a feeler gauge between the valve stem and the exhaust valve adjusting screw foot, otherwise incorrect clearance will result.
2.Please allow 1-3 mm measuring deviation due to manual measurement.
Fitment For:
For Cummins ISX Engines.
Package Include:
1x 7.0MM Engine Brake Adjustment Tool( as shown in the picture£©
Instructions:
1.Loosen the locknut on the brake lever adjusting screw, and back out the adjusting screw one turn
2.Insert the feeler gauge( 7mm-3163530), between the bottom of the engine brake piston and the top of the exhaust valve pin on the exhaust valve crosshead
3.Tighten the adjusting screw until drag on the feeler gauge is felt(Proper drag means that there is no motion of the brake lever camshaft follower against the cam lobe)
4.Hold the engine brake lever adjusting screw and tighten the locknut
Specifics:
Condition: 100% Brand New
Color: Black
Size: shown as pictures
Type: Engine Brake Adjustment Tool(7MM)
Material: Steel
Note£º
1.Do not insert a feeler gauge between the valve stem and the exhaust valve adjusting screw foot, otherwise incorrect clearance will result.
2.Please allow 1-3 mm measuring deviation due to manual measurement.
Fitment For:
For Cummins ISX Engines.
Package Include:
1x 7.0MM Engine Brake Adjustment Tool( as shown in the picture£©
