100A MPPT Solar Controller Multi-language Color Screen Serial Port MPPT Solar Controller Bluetooth Temperature Monitoring Charging 12V~60V

Safety Instructions:
1.When charging lithium battery, you must bring the battery protection board, and be sure to choose the products of lithium battery manufacturers that have been certified to meet national requirements.
2.When the battery OV start and battery repair functions are used, it is necessary to remember the battery voltage value that needs to be charged for the first time.
3.The controller can only use photovoltaic panels as the charging source. Please do not use DC or other power sources as the charging source.
4.The controller will heat up when running. Please pay attention to install the controller in a flat, well-ventilated and rainproof position.

Features:
1.This controller is charged with 12/24/36/48/60V batteries and supports Bluetooth mobile app operation, efficient and convenient.
2.Color screen displays all functions, multiple language operations, and accurate real-time temperature display on the same screenCharging current, discharging current, cumulative power generation, photovoltaic and battery working status, etc.
3. Automatic focusing MPPT tracking charging, high charging efficiency, and non-stop detection during the charging process, Bidirectional focus tracking
4.Built in overheating, overcurrent, short circuit, open circuit protection, reverse connection protection, when the fault is eliminated, The controller automatically recovers without damaging the equioment
5.External battery and device temperature monitoring, turn off charging or discharging when the temperature is too high. Can be turned onControl and read machine data through serial port.

Specifications:
Type: MPPT Controller
Color: Blue
Rated charging current: 100A
Rated discharging current: 30A
System Voltage:12V/24V/36V/48V/60V
Self-Consume: <20mA
USB output: 5V/2A Max
Operating Temperature: -10-+60℃
Siez/Weight : 170×95×45mm/330g

Package included:
1x MPPT Solar Controller
1 x User Manual
