Magneto Generator Engine Stator Coil For Yamaha Cruiser Waverunner FX 1000/1100 AR230 SR230 SX230 2002-2009
FEATURES:
Direct replacement to your original unit
Plug-and-play, direct fit, easy installation.
Highest grade lamination materials.
Highest grade copper windings, resistant to 200 degrees Celsius.
Pick up pulsar coil included.
Connector included.
All products shipped are tested.
SPECIFICATIONS:
Condition: Aftermarket 100% Brand New
Quanity: 1PC
Type: Generator Stator Coil
Replacement Part Number:60E-81410-00 / 60E-81410-01
Dimensions :
Interior diameter : 42mm / 1.64"
Exterior diameter : 103mm / 4.08"
Thickness : 13mm / 0.51"
Other specifications :
Number of wires: 6
Number of pins: 6
Number of plugs: 2
Number of fixation holes: 3(+1)
Fixation holes length: 41mm / 1.61"
FITMENT:
For Yamaha Waverunner FX 1000 Cruiser 2003-2008
For Yamaha AR230 HO 2005-2009
For Yamaha SX230 HO 2005-2009
For Yamaha Waverunner FX 1100 Cruiser HO 2004-2008
For Yamaha Waverunner FX 1100 HO 2004-2008
For Yamaha Waverunner FX 1000 2005-2008
For Yamaha AR230 2004-2006
For Yamaha SR230 2003-2005
For Yamaha SX230 2004-2006
For Yamaha Waverunner FX 1000 FX 140 2002-2004
For Yamaha 212 SS 2008-2010
For Yamaha 212 X 2008-2010
For Yamaha 232 Limited 2008-2009
For Yamaha 232 Limited S 2009
For Yamaha SR230 HO 2007
PACKAGE INCLUDED:
1x Generator Stator Coil
NOTICE:
Before installing your new stator
Check the AC output of the stator.
Replace any burned or corroded connectors on stator and regulator/rectifier.
Check and repair any melted wiring.
Use hi-temp dielectric grease on all connectors
Our stator may use a different wire color code than your original.
All of the wires are installed in the correct order; please do not change any of the wiring configurations.
This stator is designed as a direct plug-in replacement and should be used as such.
When bolting stator in, always use locking compound.
If our stator includes a pickup coil, always make sure the air gap is correct upon installation.
All item pictures are accurate; if in doubt do not hesitate to compare our item to your original part.
FEATURES:
Direct replacement to your original unit
Plug-and-play, direct fit, easy installation.
Highest grade lamination materials.
Highest grade copper windings, resistant to 200 degrees Celsius.
Pick up pulsar coil included.
Connector included.
All products shipped are tested.
SPECIFICATIONS:
Condition: Aftermarket 100% Brand New
Quanity: 1PC
Type: Generator Stator Coil
Replacement Part Number:60E-81410-00 / 60E-81410-01
Dimensions :
Interior diameter : 42mm / 1.64"
Exterior diameter : 103mm / 4.08"
Thickness : 13mm / 0.51"
Other specifications :
Number of wires: 6
Number of pins: 6
Number of plugs: 2
Number of fixation holes: 3(+1)
Fixation holes length: 41mm / 1.61"
FITMENT:
For Yamaha Waverunner FX 1000 Cruiser 2003-2008
For Yamaha AR230 HO 2005-2009
For Yamaha SX230 HO 2005-2009
For Yamaha Waverunner FX 1100 Cruiser HO 2004-2008
For Yamaha Waverunner FX 1100 HO 2004-2008
For Yamaha Waverunner FX 1000 2005-2008
For Yamaha AR230 2004-2006
For Yamaha SR230 2003-2005
For Yamaha SX230 2004-2006
For Yamaha Waverunner FX 1000 FX 140 2002-2004
For Yamaha 212 SS 2008-2010
For Yamaha 212 X 2008-2010
For Yamaha 232 Limited 2008-2009
For Yamaha 232 Limited S 2009
For Yamaha SR230 HO 2007
PACKAGE INCLUDED:
1x Generator Stator Coil
NOTICE:
Before installing your new stator
Check the AC output of the stator.
Replace any burned or corroded connectors on stator and regulator/rectifier.
Check and repair any melted wiring.
Use hi-temp dielectric grease on all connectors
Our stator may use a different wire color code than your original.
All of the wires are installed in the correct order; please do not change any of the wiring configurations.
This stator is designed as a direct plug-in replacement and should be used as such.
When bolting stator in, always use locking compound.
If our stator includes a pickup coil, always make sure the air gap is correct upon installation.
All item pictures are accurate; if in doubt do not hesitate to compare our item to your original part.
